Time to spice up your color changes! You're going to learn how to animate background color changes in SwiftUI using Paths
and AnimatableData
!
Getting Started
The key to our background color changing magic is going to be creating our own custom SwiftUI Shape
struct. We'll call it SplashShape
. Shape
structs utilize the function path(in rect: CGRect) -> Path
to define what they look like. This is the function we'll be using to create the various animations.
Create the SplashShape
struct
Go ahead and create a new Shape
struct called SplashStruct
.
import SwiftUI
struct SplashShape: Shape {
func path(in rect: CGRect) -> Path {
return Path()
}
}
For starters we'll be creating two animations. leftToRight
and rightToLeft
shown below.
SplashAnimation
We will create an enum
called SplashAnimation
for our custom animations. This will allow us to easily add more animations in the future (see the end for more!).
import SwiftUI
struct SplashShape: Shape {
public enum SplashAnimation {
case leftToRight
case rightToleft
}
func path(in rect: CGRect) -> Path {
return Path()
}
}
In our path()
function we'll switch on which animation our shape is using and generate the required Path
for the animation. But first we must create variables to hold the animation type as well as progress of the aniamtion.
import SwiftUI
struct SplashShape: Shape {
public enum SplashAnimation {
case leftToRight
case rightToleft
}
var progress: CGFloat
var animationType: SplashAnimation
func path(in rect: CGRect) -> Path {
return Path()
}
}
progress
will be a value between 0
and 1
, which will detail how far we are through the animation of the color change. This will come in handy next when we write our path()
function.
Writing the path()
function
As said earlier we need to figure out what type of animation we're using in order to return the correct Path
. Start off by writing a switch
statement in your path()
function using the animationType
defined earlier.
func path(in rect: CGRect) -> Path {
switch animationType {
case .leftToRight:
return Path()
case .rightToLeft:
return Path()
}
}
As of right now this will return empty paths. We need to actually create the functions to animate the paths.
Create The Animation Functions
Below your path()
function, create two new functions called leftToRight()
and rightToLeft()
for each type of animation. Within each function we will create a Path
in the shape of a rectangle that will grow over time according to our progress
variable.
func leftToRight(rect: CGRect) -> Path {
var path = Path()
path.move(to: CGPoint(x: 0, y: 0)) // Top Left
path.addLine(to: CGPoint(x: rect.width * progress, y: 0)) // Top Right
path.addLine(to: CGPoint(x: rect.width * progress, y: rect.height)) // Bottom Right
path.addLine(to: CGPoint(x: 0, y: rect.height)) // Bottom Left
path.closeSubpath() // Close the Path
return path
}
func rightToLeft(rect: CGRect) -> Path {
var path = Path()
path.move(to: CGPoint(x: rect.width, y: 0))
path.addLine(to: CGPoint(x: rect.width - (rect.width * progress), y: 0))
path.addLine(to: CGPoint(x: rect.width - (rect.width * progress), y: rect.height))
path.addLine(to: CGPoint(x: rect.width, y: rect.height))
path.closeSubpath()
return path
}
Then utilize the two new functions in your path()
function above.
func path(in rect: CGRect) -> Path {
switch animationType {
case .leftToRight:
return leftToRight(rect: rect)
case .rightToLeft:
return rightToLeft(rect: rect)
}
}
AnimatableData
In order to make sure Swift knows how to animate our Shape
when the progress
variable is changed, we need to specify which variable is animating. Just below our progress
and animationType
variables, define animatableData
. It's a variable based on the Animatable
protocol which helps SwiftUI know how to animate views when they change.
var progress: CGFloat
var animationType: SplashAnimation
var animatableData: CGFloat {
get { return progress }
set { self.progress = newValue}
}
Animating the Color Change
Up to now we've created a Shape
which will animate over time. Next we need to add this shape to a view and automatically animate it when the view's color changes. This is where SplashView
comes in to play. We're going to create a SplashView
to automatically update the progress
variable of SplashShape
. When SplashView
receives a new Color
it triggers the animation.
Get started by creating the SplashView
struct.
import SwiftUI
struct SplashView: View {
var body: some View {
// SplashShape Here
}
}
Remember our SplashShape
takes a SplashAnimation
enum as a parameter so we'll need to add this as a parameter to our SplashView
. In addition, we're animating the background color change of the view, so we'll need to take in a Color
as well. Our initializer is detailed below.
ColorStore
is a custom ObservableObject. It is used to recieve Color
updates in the SplashView
struct, so that we can initiate the SplashShape
animation, and ultimately the background color change. We'll show how that works in a second.
struct SplashView: View {
var animationType: SplashShape.SplashAnimation
@State private var prevColor: Color // Stores background color
@ObservedObject var colorStore: ColorStore // Send new color updates
init(animationType: SplashShape.SplashAnimation, color: Color) {
self.animationType = animationType
self._prevColor = State<Color>(initialValue: color)
self.colorStore = ColorStore(color: color)
}
var body: some View {
// SplashShape Here
}
}
class ColorStore: ObservableObject {
@Published var color: Color
init(color: Color) {
self.color = color
}
}
Creating the SplashView
body
Inside the body
variable we need to return a Rectangle
set to the current color of the SplashView
. Then using the ColorStore
Obseravble Object defined earlier, we can receive color updates to animate our view.
var body: some View {
Rectangle()
.foregroundColor(self.prevColor) // Current Color
.onReceive(self.colorStore.$color) { color in
// Animate Color Update Here
}
}
When changing the colors, we need some way to keep track of the color that the SplashView
is being changed to, as well as the progress. We'll define the layers
variable in order to do this.
@State var layers: [(Color,CGFloat)] = [] // New Color & Progress
Now back inside our body
variable we need to add the newly received Colors
to the layers
variable. When we add them, we set the progress to 0
since they were just added. Then, over the course of half a second we animate their progress to 1
.
var body: some View {
Rectangle()
.foregroundColor(self.prevColor) // Current Color
.onReceive(self.colorStore.$color) { color in
// Animate Color Update Here
self.layers.append((color, 0))
withAnimation(.easeInOut(duration: 0.5)) {
self.layers[self.layers.count-1].1 = 1.0
}
}
}
As of right now, this will add the new colors to the layers
variable, but they aren't displayed on top of the SplashView
. To do this we need to display each layer as an overlay on the Rectangle
inside the body
variable.
var body: some View {
Rectangle()
.foregroundColor(self.prevColor)
.overlay(
ZStack {
ForEach(layers.indices, id: \.self) { x in
SplashShape(progress: self.layers[x].1, animationType: self.animationType)
.foregroundColor(self.layers[x].0)
}
}
, alignment: .leading)
.onReceive(self.colorStore.$color) { color in
// Animate color update here
self.layers.append((color, 0))
withAnimation(.easeInOut(duration: 0.5)) {
self.layers[self.layers.count-1].1 = 1.0
}
}
}
Give it a Run
Using the code below you can give it a run inside an emulator. What this does, is when the button inside ContentView
is pressed, it advances the index
used to select the SplashView
color, which triggers an update to the ColorStore
inside. This make the SplashView
add a SplashShape
layer and animate it's addition to the view.
import SwiftUI
struct ContentView: View {
var colors: [Color] = [.blue, .red, .green, .orange]
@State var index: Int = 0
@State var progress: CGFloat = 0
var body: some View {
VStack {
SplashView(animationType: .leftToRight, color: self.colors[self.index])
.frame(width: 200, height: 100, alignment: .center)
.cornerRadius(10)
.shadow(color: Color.black.opacity(0.2), radius: 10, x: 0, y: 4)
Button(action: {
self.index = (self.index + 1) % self.colors.count
}) {
Text("Change Color")
}
.padding(.top, 20)
}
}
}
Not Finished Yet!
We're missing one thing. AS of right now, we're continuously adding layer upon layer to our SplashView
. We need to make sure we delete those layers after they finish animating and are displayed.
Inside your onReceive()
function inside your SplashView
struct's body
variable, make the following change:
.onReceive(self.colorStore.$color) { color in
self.layers.append((color, 0))
withAnimation(.easeInOut(duration: 0.5)) {
self.layers[self.layers.count-1].1 = 1.0
DispatchQueue.main.asyncAfter(deadline: .now() + 0.5) {
self.prevColor = self.layers[0].0 // Finalizes background color of SplashView
self.layers.remove(at: 0) // removes itself from layers array
}
}
}
This makes sure we delete old entries to the layers
array and that our SplashView
is showing the correct background color based on the latest update.
Show us What You Made!
Have you completed one of our tutorials? Send us a screenshot or drop us a link to the project. We'll be featuring user's finished work on our website. Find us on Twitter @TrailingClosure, or email us at [email protected]
Source Code Posted on GitHub
Checkout the source code for this tutorial on my Github! Full source code for both SplashShape
and SplashView
are included, in addition to the examples shown. .... But wait, there's more!
EXTRA CREDIT!
If you're familiar with this blog, you know we love our extra credit 😉. I said in the beginning there would be more animations. This is the moment you've been waiting for.... drum roll....
SplashAnimation
🥳
Wooohoo!! Remember this? I told you we'd come back to it to add more animation types.
enum SplashAnimation {
case leftToRight
case rightToLeft
case topToBottom
case bottomToTop
case angle(Angle)
case circle
}
func path(in rect: CGRect) -> Path {
switch self.animationType {
case .leftToRight:
return leftToRight(rect: rect)
case .rightToLeft:
return rightToLeft(rect: rect)
case .topToBottom:
return topToBottom(rect: rect)
case .bottomToTop:
return bottomToTop(rect: rect)
case .angle(let splashAngle):
return angle(rect: rect, angle: splashAngle)
case .circle:
return circle(rect: rect)
}
}
I know what you're thinking... "Whoa, that's a lot of extra credit...". Don't fret. By modifying our path()
function inside SplashShape
, and creating just a few more functions, we'll be animating like no one's business.
Let's take this animation by animation...
topToBottom
& bottomToTop
Much like leftToRight
and rightToLeft
these functions create a path which starts from the bottom or top of the shape and grows over time using the progress
variable.
func topToBottom(rect: CGRect) -> Path {
var path = Path()
path.move(to: CGPoint(x: 0, y: 0))
path.addLine(to: CGPoint(x: rect.width, y: 0))
path.addLine(to: CGPoint(x: rect.width, y: rect.height * progress))
path.addLine(to: CGPoint(x: 0, y: rect.height * progress))
path.closeSubpath()
return path
}
func bottomToTop(rect: CGRect) -> Path {
var path = Path()
path.move(to: CGPoint(x: 0, y: rect.height))
path.addLine(to: CGPoint(x: rect.width, y: rect.height))
path.addLine(to: CGPoint(x: rect.width, y: rect.height - (rect.height * progress)))
path.addLine(to: CGPoint(x: 0, y: rect.height - (rect.height * progress)))
path.closeSubpath()
return path
}
circle
If you remember some of your grade school geometry, you'll know the Pythagorean Theorem. a^2 + b^2 = c^2
a
and b
can be considered our rectangle's height
and width
. This allows us to solve for c
, the radius of the circle that is required to cover the entirety of the rectangle. We can build the circular path from this and grow it over time using the progress
variable.
func circle(rect: CGRect) -> Path {
let a: CGFloat = rect.height / 2.0
let b: CGFloat = rect.width / 2.0
let c = pow(pow(a, 2) + pow(b, 2), 0.5) // a^2 + b^2 = c^2 --> Solved for 'c'
// c = radius of final circle
let radius = c * progress
// Build Circle Path
var path = Path()
path.addArc(center: CGPoint(x: rect.midX, y: rect.midY), radius: radius, startAngle: Angle(degrees: 0), endAngle: Angle(degrees: 360), clockwise: true)
return path
}
angle
This one is a little more involved. You need to calculate the slope of the angle using the tangent. Then create a line with the given slope. You'll plot this line as a right triangle as you move the line across the rectangle. See the picture below. The various colored lines represent the line moving over time to cover the entire rectangle.
The function is as follows:
func angle(rect: CGRect, angle: Angle) -> Path {
var cAngle = Angle(degrees: angle.degrees.truncatingRemainder(dividingBy: 90))
// Return Path Using Other Animations (topToBottom, leftToRight, etc) if angle is 0, 90, 180, 270
if angle.degrees == 0 || cAngle.degrees == 0 { return leftToRight(rect: rect)}
else if angle.degrees == 90 || cAngle.degrees == 90 { return topToBottom(rect: rect)}
else if angle.degrees == 180 || cAngle.degrees == 180 { return rightToLeft(rect: rect)}
else if angle.degrees == 270 || cAngle.degrees == 270 { return bottomToTop(rect: rect)}
// Calculate Slope of Line and inverse slope
let m = CGFloat(tan(cAngle.radians))
let m_1 = pow(m, -1) * -1
let h = rect.height
let w = rect.width
// tan (angle) = slope of line
// y = mx + b ---> b = y - mx ~ 'b' = y intercept
let b = h - (m_1 * w) // b = y - (m * x)
// X and Y coordinate calculation
var x = b * m * progress
var y = b * progress
// Triangle Offset Calculation
let xOffset = (angle.degrees > 90 && angle.degrees < 270) ? rect.width : 0
let yOffset = (angle.degrees > 180 && angle.degrees < 360) ? rect.height : 0
// Modify which side the triangle is drawn from depending on the angle
if angle.degrees > 90 && angle.degrees < 180 { x *= -1 }
else if angle.degrees > 180 && angle.degrees < 270 { x *= -1; y *= -1 }
else if angle.degrees > 270 && angle.degrees < 360 { y *= -1 }
// Build Triangle Path
var path = Path()
path.move(to: CGPoint(x: xOffset, y: yOffset))
path.addLine(to: CGPoint(x: xOffset + x, y: yOffset))
path.addLine(to: CGPoint(x: xOffset, y: yOffset + y))
path.closeSubpath()
return path
}
Support Future Tutorials Like This One!
Please consider subscribing using this link. If you aren't reading this on TrailingClosure.com, please come check us out sometime!
If you've built something using this tutorial, send us pics! Find us on Twitter @TrailingClosure, or email us at [email protected]
